Slatwall Machine 1325 CNC Router for Slat Wall Panel Making
Product Name:
Slatwall Machine 1325 CNC Router for Slat Wall Panel Making
No. :
EA-1325V45 for slatwall display fixture making
:
:



Slatwall machine can be 1325 cnc router also can be multi spindle cnc router according to different demand of clients. (check our latest design here: cnc machine router for mdf ) EagleTEC-1325V45 is slatwall tool panel or cube wall making machine. It can do MDF slatwall panel cutting, MFC slat wall panel cutting, melamine slatwall panel cutting and slotting on the panels with size 4×8 feet. You can see, there is only cutting and slotting jobs in process of slatwall panel making. Based on this machining feature, slatwall machine EA-1325V45 is equipped with 4.5kw spindle and big torque drive motor. To learn more how to make slatwall panel, please click here

Looking for cutter tool for slatwall panel making? Please click slatwall router bits

For understanding well, here is a working video of slatwall making.

slatwall machine

Application

Material: Solid wood, MDF, plastic, PVC, acrylic, and other nonmetal materials.

Field: slatwall display fixture, slot wall, wood door, panel furniture, euro-style furniture, wall art dector panel, sign and etc.

1325 cnc router machining slatwall

slatwall panelslatwall mdf panels cutting sampleslatwall display fixture

Features
1) This slatwall machine is suitable for sheet size 4x8 feet; but models for 5x10 and 6.5x13 are also available, they are slot wall machine 1530 and cnc wood router 2040.

2) Adopting vacuum table design, which makes sheet fixed easier.

3) X and Y axis motion is via rack and pinion, which is more suitable for cutting and ground for fast cutting.

4) Z axis use rolling ballscrew transmission.

5) Each axis of motion is supported on high precision HIWIN linear guide ways which

allow for higher feed speeds and a better quality of cut.

6) The Y-axis uses a dual drive, one motor for each side of the gantry.

7) All the linear guides are centrally lubricated from a central system.


Slatwall Panle Making CNC Router Technical Parameter

Working Size | 1300×2500×200mm (XYZ)

Spindle | 4.5kw, air cooled, speed range 0-18,000RPM

Drive Motor | Stepping, big torque

Controller | NC studio, PC control or Mach3

Software | ArtCAM, Type 3, UcanCAM

Command | G code

Material Holding | Vacuum, also Clamp

Vacuum Pump | 5.5kw, water ring, with 230CBM air flow

Router Bit Range | 3.175 – 16mm

Max. Cutting Speed | 20,000mm/min

Working Power | AC380V/50Hz, 3Ph 4 Wire

Power Consumption | 14KW

Net Weight | 1300KGS

Packing | Fully wrapped with plastic film and then packed into plywood case

Slatwall display is a type of tool board which is always used for products display in shop and storehouse. The most common slat wall is made of wood. But there is also slot wall made of plastic and metal. Size of wood type slot wall can be customized; while the metal and plastic one is durable.


If need any further information, feel free to contact us.
