Multi Head Double Head CNC Wood Router Machine
Product Name:
Multi Head Double Head CNC Wood Router Machine
No. :

Multi Head Double Head CNC Wood Router Machine

Model. EA-1325MH2


Material: Solid wood, MDF, plastic, PVC, acrylic, and other nonmetal materials.
multi head double head cnc wood router machine

Features of Multi Head Double Head CNC Wood Router Machine

l  This construction makes the machine can work like a basic type cnc router as well as a double spindle cnc router. Using one or two head, as you like, very convenient.

l  Frame is welded with seamless steel structure; processed by high temperature

tempering treatment and vibrating stress relief (VSR) to reduce residual stress; and it is supported by 6 legs with adjustable leveling feet.

l  Beam is made of steel. A steel beam is superior to a aluminum in it’s ability to

suppress and absorb the forces created during cutting. It is internally ribbed in order to stiffen the assembly; this design is minimizing the vibration while increasing accuracy and repeatability.

l  The X and Y axis motion is via a rack and pinion drive, which is hardened for

extremely long life and ground for a very good accuracy; The Z axis is driven by a hardened Germany rolling antibacklash ball screw.

l  Each axis of motion is supported on high precision linear guide ways. Hiwin linear

guides allow for higher feed speeds and a better quality of cut.

l  The Y-axis uses a dual drive, one for each side of the gantry.

l  Well compatibility: CAD/CAM designing software e.g. Type 3/Artcam/UcanCAM etc.

l  Has the function of re-carving after break point and power failure.

l  All the linear guides are centrally lubricated from a central system.

Technical Parameter of Multi Head Double Head CNC Wood Router Machine

Working Size (X Y Z)

650×2500×200 mm - 2
1300×2500×200 mm - 1

Driving Motor






Max.Traveling Speed

30,000 mm/min

Max.Working Speed

12,000 mm/min


By clamp

Vacuum Pump


X Y Transmission

Helical rack and pinion , HIWIN square linear guide way

Z Transmission

Taiwan TBI rolling ballscrew , HIWIN square linear guide way


4.5kw , water cooling, 0-18000 rpm variable speed

Collet Size

ER25, available diameter of cutter  φ3.175-φ16mm

Working Power

AC 380V/50-60Hz, 3 Ph 4 Wire

Max.Power Consumption


Net Weight

1200 KGS


Plywood case suitable for sea shipment
